For instance, if you have two scopes, a 4x40 and a 10x40. Higher magnification also reduces the brightness of the image. We will study more about the advantages and disadvantage of FFP and SFP scopes, when we study the topic of scopes and rangefinding tomorrow. Some high end European manufacturers make FFP scopes on request. Americans tend to prefer scopes with reticles mounted SFP and this is used in the majority of the scopes. closer to the eyepiece), then the size of the reticle remains a constant, irrespective of the magnification power. If the reticle is mounted on the second focal plane (i.e. If the reticle is mounted at the first focal plane, then the size of the reticle resizes with the target (i.e.) if the user adjusts the magnification to zoom into the target, the reticle also appears to enlarge in size and if the user adjusts the magnification to zoom out of the target, the reticle also appears in decrease in size correspondingly. For fixed power scopes, it doesn't make any difference which focal plane the reticle is mounted at, but it makes a difference for variable power scopes. Reticles may be mounted inside the telescope tubes in one of two spots: the first focal plane (FFP) or the second focal plane (SFP). Red happens to be the color that least interferes with the user's night vision. The nice thing about this is that tritium glows for a long time and could last 11 years or more before the tritium tube needs to be replaced.Īs you may have observed in movies, if the crosshairs are backlit, they are usually red, though some products use green or yellow. The tritium slowly decays and emits light as it does so. The third method, which is used in military scopes, such as the Trijicon ACOG, or the British SUSAT sight, is to use tritium, which is a mildly radioactive form of hydrogen, to provide illumination. The user may also be able to change the color of the backlight illumination, if the LED method is used. While this method requires the user to carry a battery with the scope, it has the advantage that the user can usually adjust the brightness by turning a knob. Another technique is to use a battery powered LED to provide enough light to illuminate the reticle. The first is to use a bit of fiber optic cable to collect ambient light from the outside of the scope and deliver it inside to the reticle. The illumination is usually provided by a few methods. Modern scopes usually coat the glass with special coatings designed to minimize the reflected light.įor aiming in low light conditions, many scopes have illuminated reticles. The etched lines block off a bit more light and the thin glass plate may reflect some of the light back instead of letting it through. This allows them to have features such as estimating range and bullet drop (such as that seen in the Modern Rangefinding and the SVD type above). The etched lines allow for more complex crosshair shapes, including circles, lines that don't need to touch or have gaps in between. The thin plate of glass is then mounted inside the scope. The nice thing about wire reticles is that they don't block out much light and are very durable.Īnother technique to make the crosshair lines is to etch the lines onto a thin plate of glass, using a diamond cutter. By flattening the wire in different places, the manufacturer can make Duplex Crosshairs or Target Dot type crosshairs. The wires are mounted on the inside of the telescope tube. Later on, they were made of thin wires (and many scopes still use wire crosshairs to this day, especially cheaper ones). The thick lines allow the user to quickly figure out where the center of the reticle is and the thinner lines allow for precision aiming.īack in the day, the crosshairs of reticles were made of natural fibers, such as hair or spiderweb. Examples of this would be the Duplex Crosshair, the Mil-Dot and the Modern Rangefinding reticle above. Therefore, modern telescopic sights use a mixture of both (i.e.) thicker lines on the outside and thinner lines closer to the middle. Thicker lines are more visible, but they block out more of the image and lose some precision. However, it is easier for the user to lose sight of the lines, especially in complex backgrounds.
Fine crosshairs allow the user to see more of the target and do not block out much light. Thanks to movies, most people are familiar with the Fine Crosshair type of reticle above.
